The Traces folder in the Configuration tab, shown in the following image, contains settings for the Two Way Email feature. This folder is only available if you have installed Two Way Email.
The Two Way Email folder contains the following configuration settings.
|
Setting |
Optional or Required/Default Value |
Descriptions and Possible Values |
|---|---|---|
|
Enabled |
Default is No. |
Selections are:
|
|
Two Way Default section | ||
|
Two Way Server Name |
Required Default value is EDASERVE. |
Default WebFOCUS Reporting Server for Two-Way Email requests. Two-Way Email does not support multiple WebFOCUS Reporting Servers. Two Way Email requests run against one dedicated server. Selections are
|
|
Two Way User |
Required |
Default Execution ID and password. This ID is used when a Two-Way Email subscriber selects the default check box for WebFOCUS credentials during a subscription. |
|
Account |
No default. |
Full e-mail address used as the sender and reply address for the Two-Way Email listener. Should be equivalent to MAILUSER@MAILSERVER |
|
Error Account |
No default. |
An e-mail box to which all unknown e-mails (for example, e-mails lacking a proper Two-Way Email tag) will be forwarded. |
|
Default Two Way Reply Account |
No default. |
Enables you to override and provide a different Reply Address than the e-mail address specified in the Account setting. |
|
Event Log |
Default value is On. |
Controls what Two-Way Email inbox events should be logged. On displays all events. Error displays only errors. Off turns off the Event Log. Nothing displays. |
|
Two Way Report Type |
Default value is Inline. |
Controls the type of report delivered by Two-Way Email. Other options are:
Note: In order to use the Active HTML Attachment option, you must be licensed to run Active HTML reports. |
|
Mail Server |
Required |
POP3 or IMAP mail server. You can also specify a port for the Mail Server using hostname:port. If you do not specify a port or the port you specify is not present, the default port is used. |
|
Protocol |
Default value is Pop3. |
Controls the post-office protocol to be used to connect to the Two-Way Email inbox. Set to either Pop3 or Imap. For z/OS platforms, only Imap is supported. |
|
Mail User |
Any alphanumeric string. No Default value. |
Two-Way inbox logon user ID and password. |
|
Mail Frequency |
Any integer. Default value is 60 seconds. |
Frequency to poll the inbox (n seconds between each poll). |
